Ballistic Range Rubber Sheet™

Why Ballistic Range Rubber?

Splinter Protection

Engineered to help contain bullet fragments and splinters within shooting range environments, supporting safer operational conditions.

Anti-Ricochet Performance

High elasticity and energy absorption help reduce projectile rebound, a critical requirement for indoor and outdoor shooting range systems.

Fragment Containment

Designed for fragment containment systems and bullet trap applications where retaining projectile material within the range boundary is essential.

Noise Dampening

The natural rubber matrix provides inherent noise dampening properties, beneficial for indoor shooting range environments and enclosed training facilities.

High Elasticity & Recovery

800% elongation at break with 75% resilience ensures the material performs consistently across repeated impact cycles in high-use range environments.

Long Service Life

Durable natural rubber compound maintains structural integrity under repeated projectile impact, supporting lower replacement frequency and reduced operational costs.

OEM & Contractor Supply

Custom thicknesses, widths, roll supply and private label manufacturing available for shooting range contractors, ballistic system manufacturers and defence infrastructure projects.

Widths up to 1500 mm

Supplied in widths up to 1500 mm in roll or cut-sheet form, enabling efficient coverage of large curtain and lining areas with minimal joins.

Typical Applications

• Shooting Range Curtains
• Splinter Protection Curtains
• Bullet Trap Systems
• Anti-Ricochet Safety Systems

• Fragment Containment Systems
• Indoor Shooting Ranges
• Outdoor Shooting Ranges
• Police Training Facilities

• Military Training Facilities
• Sports Shooting Academies
• Projection-Based Training Ranges
• Defence Training Infrastructure Projects

Available Colours & Finish Options

⬤  Black – Standard Grade

Primary Use: General shooting ranges

Benefits: Professional appearance, widely used across indoor and outdoor range installations.

Standard Availability

⬤  White – Projection Grade

Primary Use: Projection & simulator-based training ranges

Benefits: Improved projection visibility and light reflection for interactive target and simulator systems.

On Request

⬤  Red – Custom Grade

Primary Use: Custom & premium projects

Benefits: Enhanced visibility for safety-critical zones, custom and premium range installations.

MOQ Applicable

Surface Finish Comparison

Feature	Texture Finish (Recommended)	Smooth Finish
Glare	✓ Low	Higher
Projection Quality	✓ Better	Moderate
Wear Appearance	✓ Hides Marks	Marks More Visible
Industry Preference	✓ Preferred by OEMs	Application Specific

Both finishes are available. Texture finish is the industry-preferred option for most range applications.

V1035 Technical Specifications

Product Reference V1035 – Ballistic Range Rubber Sheet™
Property	Test Method	Value
Polymer Base	—	Natural Rubber
Hardness	DIN 53505	35 ± 5 Shore A
Specific Gravity	DIN 53508	1.0 g/cm3
Tensile Strength (min.)	DIN 53504	25 N/mm2
Elongation at Break (min.)	DIN 53504	800%
Resilience	—	75%
Thickness Range	—	2 mm – 12 mm
Width	—	Up to 1500 mm
Colours	—	Black, White, Red
Surface Finish	—	Texture / Smooth
Supply Form	—	Rolls or Cut Sheets

  Specifications are indicative and subject to standard tolerances. Technical changes may be made without prior notice. Please contact us for project-specific technical documentation.

OEM & Range Builder Supply

Designed For

• Shooting Range Contractors
• Ballistic System Manufacturers
• Bullet Trap Manufacturers
• Defence Infrastructure Contractors
• Police Training Facility Developers
• Range System Integrators

Custom Manufacturing Available

• Custom Thicknesses
• Custom Widths
• Roll Supply
• Cut-to-Size Sheets
• Private Label Manufacturing
• Export Supply

Why Vardhman?

1980

Manufacturing Since

40+

Countries Served

100%

In-House Compounding

OEM

Manufacturing Expertise

• Manufacturing Since 1980
• Integrated Rubber Compounding Facility
• Exporting to 40+ Countries
• OEM Manufacturing Expertise
• Consistent Quality Systems
• Technical Support for Project Applications

For Range Designers & Contractors

Supports shooting range curtain, rubber backstop and indoor range baffle requirements. Technical datasheet and sample evaluation available on request.

For Defence & Law Enforcement

Suitable for military training facilities, police academies, live-fire areas, fragment containment zones and defence infrastructure projects requiring reliable range safety materials.

For B2B & Export Supply

Vardhman supplies technical rubber products globally. OEM manufacturing, private label and project-based export supply available for international contractors and distributors.

Frequently Asked Questions

What is Ballistic Range Rubber Sheet?

Ballistic Range Rubber is a high-elasticity natural rubber sheet designed for splinter protection curtains, anti-ricochet systems, bullet trap applications and shooting range safety systems.

What are the typical applications?

Common applications include:

• Shooting range curtains
• Splinter protection systems
• Anti-ricochet barriers
• Bullet trap systems
• Fragment containment systems
• Police and military training ranges
• Defence training applications / infrastructure projects
• Sports shooting facilities

Is the material bulletproof?

No. Ballistic Range Rubber is not intended to function as body armour or bulletproof protection. It is designed to assist with fragment containment, splinter protection and anti-ricochet performance within shooting range environments.

What thicknesses are available?

Standard thicknesses: 2 mm, 3 mm, 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm. Custom thicknesses may be available upon request.

What widths are available?

The material can be supplied in widths up to 1500 mm. Custom roll lengths are also available.

What colour options are available?

Standard and custom options include:

• Black – Standard Grade (general shooting ranges)
• White – Projection Grade (on request)
• Red – Custom Grade (MOQ applicable)

Additional colours may be developed subject to minimum order quantities.

Why is White Projection Grade used?

White ballistic range rubber is often preferred in modern shooting ranges using projection systems, interactive target systems and simulator-based training. The white surface provides improved image visibility and light reflection.

Which finish is recommended?

Texture Finish is generally recommended because it offers reduced glare, better projection performance, improved aesthetics and better concealment of wear marks. Smooth finish is also available for specific applications.

Can samples be provided?

Yes. Evaluation samples are available for OEMs, shooting range contractors, ballistic system manufacturers and project developers. Please contact our technical team with your application details.

Is the material available in roll form?

Yes. The product can be supplied as rolls, cut sheets or custom-cut dimensions depending on project requirements.

Can you manufacture custom sizes?

Yes. Custom dimensions can be manufactured depending on quantity, thickness, width and application requirements.

Do you support OEM manufacturing?

Yes. Vardhman supports OEM manufacturing, private label supply, project-based supply and contractor supply for domestic and international customers.

Can the material be used outdoors?

Yes. The product may be used in outdoor shooting range environments. Material selection and installation recommendations can be discussed based on project requirements.

Is technical support available?

Yes. Our technical team can assist with material selection, thickness recommendations, sample evaluation, OEM requirements and project discussions.

Do you export Ballistic Range Rubber?

Yes. Vardhman supplies technical rubber products globally and can support international enquiries for Ballistic Range Rubber from contractors, distributors and project developers.

What information should I provide when requesting a quotation?

For a faster response, please share: application, thickness required, width required, quantity, colour preference, finish preference and country of installation.

What is the minimum order quantity?

MOQ depends on thickness, colour, customisation requirements and whether supply is export or domestic. Please contact us for project-specific details.

Can Ballistic Range Rubber be supplied with texture finish on both sides?

Yes, custom surface finish configurations may be available depending on project requirements. Please discuss your specific needs with our technical team.

How can I request a sample or technical consultation?

Contact our sales team with your application details — we will assist with sample availability, technical guidance and project discussions. Please share your application, required thickness, width, quantity and country of installation for the fastest response.

Show More FAQs

---

Looking for Ballistic Range Rubber Sheet for a shooting range, defence infrastructure or OEM project? Contact Vardhman Hoses with your application, size, thickness and quantity requirement. Evaluation samples available on request.
